Key Features & Benefits
1. 4G/3G/2G cellular with dual-SIM support
2.Interfaces: RS232/RS485/RS422, LAN/WAN, 4×LAN, Wi-Fi (802.11 b/g/n)
3.Modbus RTU–to–Modbus TCP conversion
4.Industrial reliability with watchdog and auto-reconnect
5.Advanced networking: VPN, NAT, Firewall, QoS
6.Remote management via Web UI/CLI with upgrades and logs
7.Wide 5–36V DC input with polarity and surge protection
Certifications
PRODUCT CATEGORIES
FL2 support for fast and reliable serial data transfer.
GSF 8362Q FL 2 485
Supporting extended addressing and resilient performance in noisy environments.
GSF 8362Q 485 444
Offering high-speed serial networking for complex industrial systems.
GSF 9364 485
Engineered for redundant communication in distributed control systems.
GSA 0782-D-D 485
Supporting ultra-fast cellular communication for IoT and remote monitoring.
GSF M2M 100 5G
Connectivity and enhanced reliability for field communication
GSF M2M 100R L 2
Supporting multi-network connectivity for industrial IoT deployments.
GSF M2M 200R L 2
Introduction
The GSF 8364 is a robust cellular device built on an industrial 32-bit CPU and an embedded Real-Time Operating System (RTOS) to deliver consistent, high-speed performance. Its core function is to connect a local network of serial, Ethernet, and WiFi devices to a public LTE/WCDMA cellular network for primary or backup data transmission. The gateway is ideally suited for demanding M2M fields such as intelligent transportation, smart grid, industrial automation, finance, and other applications where reliability and advanced features are paramount.
From a technical standpoint, the GSF 8364 distinguishes itself with expanded interface options, including four dedicated LAN ports and one configurable WAN/LAN port. It features standard Dual SIM support for link redundancy and carrier diversity. The software is equally advanced, offering extensive VPN server and client capabilities, a full suite of routing and security protocols, and specialized low-consumption modes. This combination of hardware and software makes it a highly capable and secure solution for complex remote networking challenges.
WiFi: IEEE802.11 b/g/n
CPU: Industrial 32bits CPU
Memory: 16MB Flash (Extendable to 64MB), 128MB DDR2 (Extendable to 256MB)
Serial: 1x RS232 (or RS485/RS422)
SIM: Standard 3V/1.8V user card interface
Antenna: Double Cellular, 1 WiFi
Power Consumption: Standby 280 to 330 mA@12VDC; Working 325 to 562 mA@12VDC; Timing shutdown 2.57 to 4.2 mA@12DVC
Dimensions: 207 x 135 x 28 mm
Weight: 790g
Protection: 1.5KV magnetic isolation (Ethernet); 15KV ESD (Serial); 15KV ESD (SIM)
Storage Temp: -40 to +85ºC
Humidity: 95% non condensing
MTBF: 50,000 hours
